Frequency Range(MHz):820-2170
    GSM/GPRS/EDGE 850/900/1800/1900MHz/2170MHz
    HSUPA/HSDPA/UMTS 2100MHz/900MHz
    CDMA 1900 MHz
    VSWR ≤1.5
    Gain: 10dbi
    Max Input power(W): 50
    Input Impedance(Ω): 50
    Polarization Type: Vertical
    Radiation: omnidirectional
    Max diameter :70mm
    Min diameter :2.5mm
    Max Wind Speed :230km/h
    Antenna Length(mm):987mm
    Cable Length(m): 3M
    Cable Type RG58 U/RG 174 default
    Connector Type : CRC9 or customized
    SMA/SSMB/CRC9/TS9/MS147/FME//MC-Card..and so on.,
    please give us notes if the connector is chosen !    、

    Mounting: Magnetic
    Housing: Black
    Weight:310g
    Storage Temperature: -45'c to +75'c
    Operating Temperature: -45'c to+75'c

The connectors / adapters we can offer you:

CRC9 connector/ adapter /Antenna for Huawei USB modem or other modem with CRC9

CRC9 connector/ adapter /Antenna for HUAWEI PCMCIA Card

CRC9 connector/ adapter /Antenna for HUAWEI Express Card ,
