2.4GHz/5GHz 6dBi double frequency Omni WIFI Antenna RP-SMA for wireless router
Model: WA2-2712-S02SP-060
    QTY 1+10+100+500+ More
    Price each. $6.42$6.10$5.40$5.07 Ask
    Saving% 0% 5%16%21% Ask
Qty:
Description
Product parameters:
    Product Type: WIFI Antenna  Input Impedance: 50Ω
    Frequency Range: 2.4GHz/5GHz  V.S.W.R.: ≤1.5
    Gain: 6dBi  Polarization: Vertical
    Connector: RP-SMA (Male)  Power: 60
    Diameter: 11.48mm  Housing: Black

This compact 2.4GHz/5GHz double frequency omnidirectional "rubber-duck" WiFi antenna provides broad coverage and 6dBi gain. It is a coaxial sleeve design with an omni-directional pattern. It is ideally suited for IEEE 802.11b and 802.11g wireless LANs
This flexible antenna features a tilt-and-swivel RP-SMA connector, allowing them to be used vertically, at a right angle, or any angle in-between. It is suitable as a replacement RF antenna for many access points and radios that are equipped with RP-SMA connectors including D-Link, Linksys and others.



Applications:
IEEE 802.11b,802.11g,802.11b/g,Wirless Lan
Omni Directional Mulitpoint applictions
Bluetooth ,Point to Mulotpoint
Pubic Wirless Hotspot
WiFi,RFID
Wireless Video Systems


Features:
Superior Performance
The Weight is light
Good appearance designs
Installed for Collinear Vertial Polarization
Multiple options
RoHS Compliant
Specification:
Frequency: 2.4GHz/5GHz
Gain :6dBi
Polarization : Vertical
Impedance : 50 Ohm
Connector : RP-SMA (Male)
Operation Temperature: -20~+60 °C
weight:29g
Diameter: 11.48mm
Flexible WiFi antenna
Tilt and swivel design
Color:Black
