This compact GSM940 omnidirectional "rubber-duck" GSM antenna provides broad coverage and 3dBi gain. It is a coaxial sleeve design with an omni-directional pattern.
This antenna features a tilt-and-swivel SMA Plug connector, allowing them to be used vertically, at a right angle, or any angle in-between. It is suitable as a replacement RF antenna for many access points and radios that are equipped with SMA male connectors including mobile, wireless pay phone, fixed commercial phone, PCMCIA card, navigation device, vehicle wireless device, etc. Works for the current digital MOBIL systems.
Product Specification :
Frequency:900-980MHz
VSWR: ≤ 2
Gain:3dB
Power：50W
Bandwidth：64MHz
Input Impedance: 50Ω
Polarization：Vertical
Directionality：omnidirectional
Horizontal Beam Width：360°
vertical panel Beam Width：90°
Color:Black
Connector:SMA Plug Tilt and swivel design
Diameter: 13.5mm
Length: 210mm
weight:30g
Notes:The default connector of the antenna is SMA male ,if you choose other connector for antenna connector ,a adapter or pigtail will be needed with this antenna to fit with your GSM/3G devices .
